EP48300ES 51.2V300AH 15kWh

home solar energy storage system
- Top brand A+ grade LiFePO4 battery cells
- Moveable / wall-mounted / floor standing
- 6000+ life cycles, 10+ years design life
- Built-in BMS with smart control
- With SOC design
- Communication protocols compatible with most inverters

Home Solar Energy Storage Battery 15KWH EP48300ES 51.2V300AH

Battery Pack Model No.	EP48300ES
Nominal Voltage	51.2V
Nominal Capacity	300Ah (15.36kWh)
Battery Type	LiFePO4
BMS	Built-in smart BMS with SOC
Open Voltage	43.2V-58.4V
Charging Cut-off Voltage	58.4V
Discharging Cut-off Voltage	44.8V
Standard Discharging Current	60A
Max. Discharging Current	300A
Max. Charging Current	100A
Load Power	≤ 15.36kW
Charging Efficiency	100% at 0.2C
Discharging Efficiency	96% ~ 99% at 1C
Self Discharge Rate	≤ 2% / month （25℃）
Life Cycle	≥ 6000 (80% DOD, 25℃)
Water Proof Rating	IP43
Charging Temperature	0 ~ 45℃
Discharging Temperature	-20 ~ 60℃
Storage Temperature	-10 ~ 45℃
Communication Protocals	CANBus / RS485 / RS232 (customization available)
Dimension	800(L)650(W)200(H)mm
Weight	≈ 136kg
Certificates	UL, CE, ROHS, MSDS, KC, BIS, UN38.3 etc.
